Table 1. Composition ranges for ASME SA 213 304 304L 304H and EN 10216-5 1.4301 1.4307 1.4948 Grade – C Mn Si P S Cr Mo Ni N 304/S30400 min.max. -0.08 -2.0 -1.00 -0.045 -0.030 18.0-20.0 – 8.0-11.0 – EN 10216-5 1.4301 min.max. -0.07 -2.0 -1.00 -0.040 -0.015 17.00-19.5 – 8.0-10.5 -0.11 304L/S30403 min.max. -0.035 -2.0 -1.00 -0.045 -0.030 18.0-20.0 – 8.0-12.0 – EN 10216-5 1.4307 min.max. -0.030 -2.0 -1.00 -0.040 -0.015 17.5-19.5 – 8.0-10.0 -0.11 304H /S30409 min.max. 0.04-0.10 -2.0 -1.00 -0.045 -0.030 18.0-20.0 – 8.0-11.0 – EN 10216-5 1.4948 min.max. 0.04-0.08 -2.0 -1.00 -0.035 -0.015 17.0-19.0 – 8.0-11.0 -0.11 Data are typical and should not be construed as maximum or minimum values for specification or for final design. Data on any particular piece of material may vary from those shown herein

Alloys 304 S30400 , 304L S30403, and 304H S30409 stainless steel tubing are variations of the 18 percent chromium – 8 percent nickel austenitic alloy, the most familiar and most frequently used alloy in the stainless steel family. These alloys may be considered for a wide variety of applications where one or more of the following properties are important: Resistance to corrosion Prevention of product contamination Resistance to oxidation Ease of fabrication Excellent formability Beauty of appearance Ease of cleaning High strength with low weight Good strength and toughness at cryogenic temperature Ready availability of a wide range of product forms Each alloy represents an excellent combination of corrosion resistance and fabricability. This combination of properties is the reason for the extensive use of these alloys which represent nearly one half of the total U.S. stainless steel production. The 18-8 stainless steel, principally Alloys 304, 304L, and 304H, are available in a wide range of product forms including sheet, strip, and plate. The alloys are covered by a variety…
