DIN 86019 Seamless Tubes Made of CuNi10Fe1.6Mn for Pipes - Dimensions for Standard Tubes and Precision Tubes
DIN 86019 CuNi10Fe1.6Mn 2.1972 Seamless Pipe / BS 2871 CN102 / EN 12449 / EN 1652
Outside Diameter of pipe
DIN 86019
10 bar
14 bar
ØOutside Diameter
Wall
Theoretical
Wall
Theoretical
Thickness
Weight
Thickness
Weight
Nominal
Actual
inch
DN
mm
mm
Kg/m
mm
Kg/m
1/8
10
1
0.26
1
0.26
1/4
12
1
0.31
1
0.31
3/8
10
16
1
0.42
1
0.42
1/2
15
20
1
0.53
1
0.53
3/4
20
25
1.5
0.99
1.5
0.99
1
25
30
1.5
1.2
1.5
1.2
11/4
32
38
1.5
1.54
1.5
1.54
1 1/2
40
44.5
1.5
1.81
1.5
1.81
2
50
57
1.5
2.34
1.5
2.34
2 1/2
65
76.1
2
4.16
2
4.16
3
80
88.9
2
4.88
2.5
6.07
4
100
108
2.5
7.41
2.5
7.41
5
125
133
2.5
9.16
3
10.95
6
150
159
2.5
10.99
3
13.14
7
175
193.7
2.5
13.43
3.5
18.7
8
200
219.1
3
18.21
3.5
21.19
10
250
267
3
22.24
4
29.55
12
300
323.9
4
35.94
5
44.78
14
350
368
4
40.89
5.5
56
16
400
419.1
4
46.62
6
69.6
18
450
457.2
4
50.91
6
76.03
20
500
508
4.5
63.63
6.5
91.55
24
600
610
5
84.96
8
135.26
28
700
711
6
118.8
9
177.45
32
800
813
6
135.99
10
225.53
36
900
914
8
203.57
11
278.98
DIN 86019 CuNi10Fe1.6Mn Standard Specification: ASTM B111 Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock ASTM B395 Standard Specification for U-Bend Seamless Copper and Copper Alloy Heat Exchanger and Condenser Tubes ASME SB466 Specification for Seamless Copper-Nickel Pipe and Tube BS 2871-2
Specification for copper and copper alloys. Tubes. Part 2: Tubes for general purposes
GB/T8890 Seamless Copper Alloy Heat Exchanger Tubes
JIS H3300 Copper and Copper Alloy-Seamless Pipes and Tubes BS 2871 CN102 CN107 CN108 CZ110 CZ111 CZ126 CZ108 C101 C102 C106 Copper and Copper Alloy Tubes
EEMUA 144 Specifications covering 90-10 Cu-Ni Piping for Offshore Applications are : Tubes Seamless and Welded Publication EEMUA 234 UNS 7060X - 90/10 Copper nickel alloy piping for offshore applications (Incorporating EEMUA 144, 145 and 146)
DIN1785 Wrought Copper and Copper Alloy Tubes for Condensers and Heat Exchangers DIN 86019 Seamless Tubes Made of CuNi10Fe1.6Mn for Pipes - Dimensions for Standard Tubes and Precision Tubes
DIN 80619 Referenced Standard:
DIN 87160-2 : 2015 METAL STRAINERS, DN 20 TO DN 200 - PART 2: COMPONENTS
UNE 27491 : 2014 CIVIL SHIPBUILDING AND SHIP REPAIRING - SELECTIVE LISTS - PIPING AND FITTINGS: COOPER-NICKEL (CUNI) TUBES (DIN)
DIN 86283-2 : 1994 PIPEWORK ON SHIPS AND MARINE STRUCTURES - DRINKING WATER SUPPLY - PART 2: METHOD OF CALCULATION
DIN 86283-1 : 1994 PIPEWORK ON SHIPS AND MARINE STRUCTURES - DRINKING WATER SUPPLY - PART 1: PLANNING AND DESIGN
DIN 87160-1 : 2015 METAL STRAINERS, DN 20 TO 200 - PART 1: ASSEMBLY
TABLE 1.Designations in Standard for 90-10 C70600 and 70-30 C71500 Copper-Nickel Alloy
Weld consumable specifications and compositions are shown in Table 3. They contain small titanium additions to counteract atmospheric contamination during welding operations.
TABLE 3. Standards and Typical All-Weld-Metal Compositions of Filler Metals
ASTM B111 Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock
